Copper
Light weight, corrosion resistant, copper is strong, ductile and malleable. High thermal conductivity Excellent conductor of electricity. Long-lasting Maintenance-free. Universal acceptability assures compliance with major building codes. Copper will not burn or support combustion,so it won't carry fire through floors, walls and ceilings. Our aluminum strip can be produced in standard dimensions or custom made to your requirements. We produce both imperial and metric units.
Global Metals provides a full range of copper products for almost any application. Our strip, coil, foil, bar, rod, pipe, plate, sheet, tube and other profiles are produced in a wide variety of alloys, including clad composites. They can be produced in standard dimensions or custom made to your requirements. Our copper products are manufactured in compliance with the main international specifications, and tighter tolerances are available upon request. We offer various platings and coatings, edge conditioning, special surface conditions, profiled strip, and multiple packaging options to meet our customers’ requirements. The following is a summary of our production capabilities.
Alloys
| No. |
UNS |
Trade Name |
EN / DIN |
| 101 |
C10100 |
Oxygen-Free Electronic |
Cu-OFE |
| 102 |
C10200 |
Oxygen-Free, without residual deoxidnants |
Cu-OF |
| 103 |
C10300 |
Oxygen-Free, extra low phosphorous |
Cu-OFXLP |
| 104 |
C10400 |
Oxygen-Free with Ag |
Cu-OFS |
| 105 |
C10500 |
Oxygen-Free with Ag |
Cu-OFS |
| 107 |
C10700 |
Oxygen-Free with Ag |
Cu-OFS |
| 110 |
C11000 |
Electrolytic Tough Pitch |
Cu-ETP |
| 113 |
C11300 |
Touch Pitch with Ag |
Cu-STP |
| 120 |
C12000 |
Deoxidized, Low Phosphorus |
Cu-DLP |
| 122 |
C12200 |
Deoxidized, High Phosphorus |
Cu-DHP |
| 143 |
C14300 |
Cadmium Copper, Deoxidized |
|
| 1442 |
C14420 |
Telurium-Bearing Copper |
|
| 1453 |
C14530 |
Telurium-Bearing Copper |
|
| 1921 |
C19210 |
Iron-Bearing Copper |
|
| 194 |
C19400 |
Iron-Bearing Copper |
CuFe2P |
| Other Alloys available upon request |
Clad Composites
Copper Alloy & Aluminum
Copper Alloy & Copper Alloy
Copper Alloy & Steel
Thickness
| Min. Gauge |
0.006" |
0.15mm |
For thinner gauges see Link |
| Max. Gauge |
0.250" |
6.35mm |
For thicker gauges see Link |
Width
| Min. Width |
0.125" |
3mm |
For narrower widths see Link |
| Max. Width |
48.00" |
1,220mm |
|
Tolerances
Our copper profiles are manufactured in compliance with the main international specifications. Tighter tolerances are available upon request. Custom tempers are available upon request.
Specifications
Manufactured in compliance with the main international specifications and standards including: ASTM, EN, and DIN. Our copper can also be manufactured to meet the requirements of other international standards, including: ASME, SAE, MIL, QQ, ISO, BS, and JIS.
Surface Finishes
Oil-free surface
Electro plating
Hot-dip tin plating
Deburred or rounded edges
Bright and polished surfaces
Coil with protective coatings
Profiled by either milling or stamping
